Models 111.10, 111.12 Pressure gauge 0-160 bar
wikaDescription
The model 111 pressure gauges are based on the proven
Bourdon tube measuring system. The deflection of the
Bourdon tube is transmitted to a movement and indicated.
The modular design enables a multitude of combinations
of case materials, process connections, nominal sizes
and scale ranges. Due to the high variance, the instrument
is suitable for use in a wide range of applications within
industry.
For mounting in control panels, the pressure gauges can,
depending on the process connection, be fitted with a
surface mounting flange or with a triangular profile ring and
mounting bracket.
The standard version of the model 111 is manufactured,
cost-optimised on modern production lines, in volumes of
several million instruments per year.
