Bourdon tube pressure gauge, Model 262.50, 0-16 bar
wikaDescription
The models 262 and 263 are high-quality Bourdon tube
pressure gauges with wetted parts from extremely corrosion-resistant Monel.
The use of high-quality materials and the robust design are
geared to applications in the chemical and process engineering industries with particularly aggressive acids or bases. The
instrument is suitable for liquid and gaseous media, also in
aggressive environments.
Scale ranges from 0 … 0.6 to 0 … 1,000 bar [0 ... 10 to
0 ... 15,000 psi] ensure the measuring ranges required for a
wide variety of applications.
The safety version is made up of a non-splintering window,
a solid baffle wall between measuring system and dial and a
blow-out back. In the event of a failure, the user is protected
at the front side, as media or components can only be ejected via the rear of the case.
For harsh operating conditions (e.g. vibrations), all
instruments are also available with an optional liquid filling.
The QR code on the dial allows instrument-specific information such as the serial number, the order number, certificates
and other product data to be retrieved from the internet easily
and in the long term.
