Hydraulic pressure gauge, Model 113.13, 0-100 bar
wikaDescription
The model 113.13 is a liquid-filled pressure gauge with
plastic case. The liquid filling causes damping of the internal
components and contributes to an increased vibration and
shock resistance. Thus the pressure gauges are suitable for
installation in machines and plants where strong vibrations
and shocks are expected.
These pressure gauges are based on the proven Bourdon
tube measuring system. The deflection of the Bourdon tube is
transmitted to a movement and indicated.
The plastic case and the window are welded together and an
O-ring seals the process connection at the case. In this way
the instrument fulfils the high requirements for IP65 ingress
protection.
With accuracy class 2.5 and the available nominal sizes 40
[1 ½"], 50 [2"] and 63 [2 ½"], this model is suited for a wide
range of applications in industry.
The mounting bracket, which is available as an option,
enables the panel mounting of pressure gauges with back
mount process connection. The nominal size 63 [2 ½"]
version with back mount process connection is alternatively
offered with a mounting flange on the front of the instrument.
This mounting flange is used when, for example, panel
mounting is only possible from the front.
